Daftar Harga Metering CT Class 0.5 & 5VA, 60-2500/5A

Untuk Informasi Ketersediaan dan Harga Terkni : Hubungi kami

Product Description

MH Current Transformer (MH CT) is used in energy metering and protection application. Designed for use in low voltage 50/60Hz network, the current transformer is installed in electrical switch board, control panel or motor control centre. High grade annealed grainoriented silicon steel is used for current transformer’s core to provide improved accuracy and linearity of measurement.

The MH Current Transformer can be directly installed onto bare copper busbar up to 720VAC rating. Available in a wide variety of dimensions and current ratio rating. Connection to the secondary winding is made via two bolt terminals. Customized model can be manufactured to
customer specification.

MH Current Transformer is designed, manufactured and tested in accordance with IEC 60044-1 and IEC 61869-1/2 standards. This ensures that each current transformer delivers accurate
measurements when operating at the rated current or within the defined accuracy limit factors.

Metering CT / Selection Guide

• Class 0.2 : For measuring the energy for revenue proposes. Maximum of 0.2% ratio error at 100% rated current.
• Class 0.5S : For measuring the energy purposes. Maximum of 0.5% ratio error from 20% rated current and above.
• Class 0.5 : For measuring the energy purposes. Maximum of 0.5% ratio error at 100% rated current.
• Class 1 : For general metering. Maximum of 1.0% ratio error at 100% rated current

Technical Data

• Construction : Tape wound toroidal
• Highest voltage : 0.72V
• Rated insulation level : 3kV 60 sec
• Rated frequency : 50 or 60Hz
• Insulating material : Homopolymer Polyvinyl Chloride
• Class of insulation : B
• Rated short-time thermal current : 60 x Ipri (100kA max)
• Applied technical standards : IEC 61869-1, IEC 61869-2
• Certificates : CE, UKCA, RoHS
